Features
- OpenMode time time/temperature programming (no restrictions on number of programs or steps)
- Intuitive 4.3” (10.9 cm) SmartTouch display
- 11 languages: French, German, Spanish, Chinese, Portuguese, Russian, Hindi, Arabic, Italian, Korean, English
- Variable speed pump with open- and closed-loop external circulation capability
- Swivel 180™ Rotating Controller
- On-board connectivity: USB-A & B, Ethernet, RS-232/RS-485, remote on/off and external temperature probe
- Event scheduling (time & date) with real-time clock
- Review temperature trends for up to 10 days
- Multiple selectable “home” screens
- On-screen help
- Automatic and/or user-adjustable performance optimization
- 10-point calibration capability
- Includes Enhanced Performance Hardware & Software Package (Pt100 temperature probe, USB flash drive for data logging, stainless steel fittings and tubing adapters, PolyScience LabVIEW Virtual Instrument, iPhone application download)
2 year manufacturer's warranty
- Manufacturer:
- Polyscience
- Part Numbers:
- AP7LR-20-A11B, 120V or AP7LR-20-A12E, 240V
- Working Temperature Range °F:
- -4°F to 392°F
- Working Temperature Range °C:
- -20°C to 200°C
- Nominal Cooling Capacity @ +20C (W):
- 200
- Reservoir Capacity:
- 1.85 gallons
- Reservoir/Tank Material:
- Stainless Steel
- Reservoir Cover:
- Included
- DuraTop:
- Yes
- LidDock:
- Yes
- Cleanable Air Filter:
- Yes
- Working Access (L x W x D):
- 6.18 x 5.59 x 5 in
- Temperature Stability °F / °C:
- ±0.02°F / ±0.005°C
- Display:
- 4.3" SmartTouch Touchscreen
- Display Resolution (Set):
- 0.01
- Display Resolution (Read):
- 0.001
- Pump Type:
- Pressure/Suction
- Pump Speed:
- Variable
- Process Connections:
- 1/4" (F) NPT
- External Temperature Control Capability:
- Yes
- Flammability Class (DIN 12876-1):
- III (FL)
- Over-Temperature Protection / Failsafe Heater Control:
- Yes
- Low Liquid Level Protection:
- Yes
- Reservoir Drain:
- Yes
- Included Software:
- PolyTemp Viewer, TDMS file viewer, USB driver, Time/Temperature Program Generator, PolyTemp Remote iPhone application
- Maximum Ambient Temperature °F / °C:
- 95°F / 35°C
- Overall Dimensions (L x W x H):
- 23.2 x 16.2 x 16.2 in
- Refrigerant:
- R134a
- Environmental Compliance:
- RoHS, WEEE
